Description
Overview
The Solaro HelioGrid 15kW is built for commercial rooftops, large villas, and small-to-medium industrial enterprises requiring reliable, high-yield three-phase energy conversion. Its dual Maximum Power Point Trackers (MPPT) allow flexible array orientations across multiple roof angles with virtually zero mismatch loss.
Key Highlights
- 98.6% Max Efficiency: State-of-the-art silicon carbide components minimize thermal dissipation and extract maximum kWh from solar arrays.
- Dual Independent MPPTs: Easily manage complex roof installations with different angles, orientations, and shading.
- Safety & Arc Fault Protection (AFCI): AI-powered arc fault circuit interrupter disconnects dangerous electrical arcs within 2.5 milliseconds.
- IP66 Weatherproof Housing: Die-cast aluminum casing withstands torrential rain, sandstorms, and extreme ambient heat up to 60°C.
Technical Specifications
| Rated AC Power | 15,000 W (15 kW) |
| AC Output Phase | 3-Phase / 380V / 400V (50/60 Hz) |
| Max. DC Input Voltage | 1,100 V |
| MPPT Voltage Range | 160 V – 1,000 V (Dual MPPT, 2 strings each) |
| Max Efficiency / Euro Efficiency | 98.6% / 98.2% |
| Cooling Mechanism | Natural convection + Smart silent variable fans |
| Display & Connectivity | OLED + LED indicators, Wi-Fi, 4G dongle, RS485 |
| Certifications | VDE-AR-N 4105, EN 50549-1, CE, IEC 62109-1/-2 |
